Back Surface Roughness 0.8~1.2μm Patterned Sapphire Substrates Round Edge
2inch Patterned Sapphire Substrates,LED Chip,Substrate Material
Patterned Sapphire Substrates (PSS) is a micro-patterned sapphire substrate. It has been widely used in high-power GaN-based Light Emitting Diodes (LEDs), which are the most promising alternative light source for general lighting. With the breakthrough of the patterned-sapphire substrate technique, the efficacy of high-brightness GaN-based LEDs has been driven to a record high of 150 lm/W.
| 2inch Patterned sapphire substrate |
| Item | Al2O3 |
|
| Dimension | 50.80±0.10mm |
| Thickness | 430±10μm |
| Flat edge width | 16±1.0mm |
| Flat edge angle | A-plane±0.2o |
| TTV | ≤5μm |
| BOW | ≤-8~0μm |
| Front Surface Roughness | ≤0.25nm |
| Back Surface Roughness | 0.8~1.2μm |
| Edge | Round |
| Laser making | back |
